OGD250

a:	sensor
b:	object
c:	background
x:	distance sensor/object [mm]
y:	min. distance object/background [mm]

1:	Background any (6...90 % remission)
2:	Background white (90 % remission)

1:	Background any (6...90 % remission)
2:	Background white (90 % remission)

1:	Background any (6...90 % remission)
2:	Background white (90 % remission)

1:	bright
2:	dark
A:	Set point
B:	Reset point
x:	object brightness ( Object reflectivity )
y:	min. reflectivity difference to be detected safely

Small compact design with standard M18 thread and PMD time-of-flight technology, measurement to the nearest millimeter and monitoring of distances in the running process, Color-independent range, Simultaneous output of distance value and reflectivity for increased process reliabilityAll information about the OGD250 at a glance. We assist you with your requirements. Technical data Mounting and Installation Instructions CAD drawings Compatible Accessories
